G652D 1550nm Anti UV LSZH Microduct Fiber Optic Cable

Brand Name : DAWNERGY

Model Number : GJFXZY-6G.652D

Certification : CE/TELCORDIA

Place of Origin : CHINA

MOQ : 100KM

Payment Terms : T/T, L/C, D/A, D/P

Supply Ability : 10,000KM PER DAY

Delivery Time : 10-20 work days

Packaging Details : Wooden DRUM

Product : Indoor/outdoor duct optical cable

Outer Sheath : LSZH, Yellow, anti-UV

Application : Indoor/outdoor duct

No. of fiber per tube : 6

Contact Now

Indoor/outdoor duct optical cable 6 fibers G652D GJFXZY-6G.652D

IdentificationGJFXZY-6G.652D
ApplicationIndoor/outdoor duct optical cable
Configuration
  • Loose tube with max 6 fibers per tube, filled with thixotropic compound
  • Strength member:Glass yarn and water blocking yarn
  • Outer sheath: LSZH, Yellow, anti-UV
Temperature Range

Storage and transport

-20 to +60°C

Installation

-20 to +60°C

Operation

-20 to +60°C

StandardsIEC 60793-1, IEC 60793-2, IEC 60794-3-10
Specification No.GL20200825323
Customer ReferenceCommon standard
  1. Dimensions
Number of fibers 6
Loose tubes x fibers 1x6
Loose tubes/Dummies 1/0
Outer diametermm6.0±0.5
Weightkg45±15%

Note: sheath thickness not consider ripcord portion, sizes and values without tolerances are nominal values

  1. Mechanical Properties
Max. tensile load Short term: 600N;long term:200N
Crush resistance / 10 cm Short term:1000 N;long term:200N
Bending radius (installation) 20x cable Ø
Bending radius (operation) 10x cable Ø

See Point 6: Test Methods

  1. Marking

G652D 1550nm Anti UV LSZH Microduct Fiber Optic Cable

  1. Optical Fiber
Standard ITU-T G.652D
Optical

Fibre attenuation
.. cabled

@ 1310 nm

≤0.36 dB/km

@ 1550 nm

≤0.22 dB/km

Mode field diameter (MFD)9.2 ± 0.4 µm@1310nm
Zero dispersion wavelength1300~1324 nm
Zero dispersion slope≤0.092 ps/nm² ∙km
Polarisation mode dispersion (PMD)≤0.2 ps/√km
Cable Cut-off wavelength≤1260 nm
GeometricOuter diameter245 ± 10 µm
Cladding diameter125 ± 1.0 µm
Core/clad concentricity error≤0.6 µm
Cladding non-circularity≤1.0 %
MechanicalProof stress≥0.69 Gpa

  1. Test Methods
TestConditionsAcceptance criteria

Tensile strength
IEC 60794-1-2 E1

Tensile strength: see Point 3
Sample length: ≥ 50 m, Duration: 1 min

  • Fiber strain≤0.6%
  • △α ≤0.1dB during test
  • No damage

Crush resistance
IEC 60794-1-2 E3

Crush: see Point 3
Test duration: 1 min, number of test: 3

  • △α ≤0.05dB after test
  • No damage

Impact
IEC 60794-1-2 E4

Impact energy: 5 J
R = 300 mm, number of places/tests: 3

  • △α ≤0.1dB during and after test
  • No damage

Torsion
IEC 60794-1-2 E7

Sample length: 2 m
± 180°, 5 cycles

  • △α ≤0.1dB during and after test
  • No damage

Repeated Bend
IEC 60794-1-2 E6

Bending radius: 20x cable Ø
25 cycles

  • No damage

Temperature cycling
IEC 60794-1-2 F1

-20℃→ +60℃
12 hours at each step, 2 cycles

  • △α≤0.15 dB/km and reversible
  • No damage

Water penetration
IEC 60794-1-2 F5

Sample length: 3 m
Water column height: 1 m
Test duration: 24 h

  • No water leakage

All optical measurements at 1550nm (G652D) or 1300 nm (OM2/OM3/OM4)

  1. Logistics
Cable type

Length

Tolerance

4km

-5% / +5%

G652D 1550nm Anti UV LSZH Microduct Fiber Optic Cable

D*d*B in cm

GJFXZY-6G.652D

Drum Type

Dimensions

Weight

Plywood suitable for indoor storage

75*35*57cm

200kg

Dimensions including protection. Indicative values, actually delivered drum sizes and weights may deviate. Cable ends sealed with caps
